Ignition

Samsung SDI’s Li-ion battery can help make a more compact and longer-lasting ignition.

By using a Li-ion battery with higher energy efficiency than a lead-acid battery, you can make a more compact ignition and ensure convenient use in the long term.

Samsung SDI Li-ion Battery - Ignition

Product features

Why the Li-ion Battery is the Best Solution for an Ignition

  • Samsung SDI Ignition Li-ion Battery - Maximized ignition performance
    Maximized ignition performance (high performance ignition)

    A Li-ion battery has an efficient peak discharge.

  • Samsung SDI Ignition Li-ion Battery - Superb Storage Characteristics
    Superb Storage Characteristics

    A Li-ion battery has a much lower self discharge rate than other batteries. Batteries slowly self discharge even if left unused, which reduces their initial capacity. A Li-ion battery retains 93% of its initial capacity after one year of storage, as compared to 60% of a lead –acid battery.

  • Samsung SDI Ignition Li-ion Battery - More eco-friendly battery
    More eco-friendly battery

    A Li-ion battery is an eco-friendly battery using no hazardous materials (e.g., Pb, Cd, Hg) or dangerous materials such as sulfuric acid (H2SO4) restricted for use under various environmental regulations.

Click on the button to move to the page.
Inquiry

Product features

Why the Li-ion Battery is the Best Solution for an Ignition

  • Samsung SDI Ignition Li-ion Battery - Proven safety and quality
    Proven safety and quality

    Samsung SDI’s Li-ion battery has a wide range of operating temperatures (-10℃ ~ 60℃) and can be safely used in hot or cold regions. Samsung SDI's batteries operate safely and reliably under any external condition such as vibration, shock, dust, and water.

  • Samsung SDI Ignition Li-ion Battery - Convenient Pin-to-Pin Compatibility
    Enhanced design flexibility with reduced weight

    A Li-ion battery has higher power density than the existing lead-acid battery. So it can reduce the battery pack’s volume and weight to 1/2-1/3 of a lead-acid battery pack of the same capacity. This is a worthy enhancement because weight reduction is critical to transportation.

  • Samsung SDI Ignition Li-ion Battery - World’s No.1 Li-ion battery provider
    World’s No.1 Li-ion battery provider

    Samsung SDI’s Li-ion battery is the most popular battery of choice in various major products around the world including IT devices, power tools, and E-bikes. This popularity serves as a testimony to the battery’s superior quality, safety, and reliability.

Product specifications

  • Samsung SDI Cylindrical Battery Cell for Ignition Cylindrical Cell Show specs
    Pack Model, Pack Capacity(Ah), Pack Voltage(V), Energy(Wh), Cell Array, Number of Cells, Cell Model, Cell Type
    Pack Model Pack Capacity
    (Ah)    		 Pack Voltage
    (V)    		 Energy
    (Wh)    		 Cell Array Number of Cells Cell Model Cell Type
    Cell Model INR 18650-11Q Type Cylindrical >Thick/Diameter (mm) 18 Height(mm) 65 Capacity(mAh) 1,100 Nomina Voltage(V) 3.20 Max Continuous Discharge Current 10

    * Cells with specification different from the above products can be provided upon customer’s request.

  • Samsung SDI Battery Pack for Ignition Pack Show specs
    Pack Model, Pack Capacity(Ah), Pack Voltage(V), Energy(Wh), Cell Array, Number of Cells, Cell Model, Cell Type
    Pack Model Pack Capacity
    (Ah)    		 Pack Voltage
    (V)    		 Energy
    (Wh)    		 Cell Array Number of Cells Cell Model Cell Type
    Pack Model 12.8V,1.1Ah Pack Capacity (Ah) 1.1 Pack Voltage (V) 12.8 Cell Array 4S1P Number of Cells 4 Cell Model IFR18650-11Q Cell Type Cylindrical
    Pack Model 12.8V,2.2Ah Pack Capacity (Ah) 2.2 Pack Voltage (V) 12.8 Cell Array 4S2P Number of Cells 8 Cell Model IFR18650-11Q Cell Type Cylindrical
    Pack Model 12.8V,4.4Ah Pack Capacity (Ah) 4.4 Pack Voltage (V) 12.8 Energy (Wh) 4S4P Cell Array 16 Cell Model IFR18650-11Q Cell Type Cylindrical
    Pack Model 12.8V,6.6Ah Pack Capacity (Ah) 6.6 Pack Voltage (V) 12.8 Cell Array 4S6P Number of Cells 24 Cell Model IFR18650-11Q Cell Type Cylindrical
    Pack Model 12.8V,11.0Ah Pack Capacity (Ah) 11.0 Pack Voltage (V) 12.8 Cell Array 4S10P Number of Cells 40 Cell Model IFR18650-11Q Cell Type Cylindrical

    * The specifications above are for Samsung SDI's representative packs.
    Samsung SDI can also provide packs with a custom specification desired by the customer.

Pack Model, Pack Capacity(Ah), Pack Voltage(V), Energy(Wh), Cell Array, Number of Cells, Cell Model, Cell Type
Cell Model Type Thick/Diameter
(mm)		 Height
(mm)		 Capacity
(mAh)		 Nominal
Voltage(V)		 Max Continuous Discharge Current
Cell Model INR 18650-11Q Type Cylindrical >Thick/Diameter (mm) 18 Height(mm) 65 Capacity(mAh) 1,100 Nomina Voltage(V) 3.20 Max Continuous Discharge Current 10

* Cells with specification different from the above products can be provided upon customer’s request.

Pack Model, Pack Capacity(Ah), Pack Voltage(V), Energy(Wh), Cell Array, Number of Cells, Cell Model, Cell Type
Pack Model Pack Capacity
(Ah)		 Pack Voltage
(V)		 Cell Array Number of Cells Cell Model Cell Type
Pack Model 12.8V,1.1Ah Pack Capacity (Ah) 1.1 Pack Voltage (V) 12.8 Cell Array 4S1P Number of Cells 4 Cell Model IFR18650-11Q Cell Type Cylindrical
Pack Model 12.8V,2.2Ah Pack Capacity (Ah) 2.2 Pack Voltage (V) 12.8 Cell Array 4S2P Number of Cells 8 Cell Model IFR18650-11Q Cell Type Cylindrical
Pack Model 12.8V,4.4Ah Pack Capacity (Ah) 4.4 Pack Voltage (V) 12.8 Energy (Wh) 4S4P Cell Array 16 Cell Model IFR18650-11Q Cell Type Cylindrical
Pack Model 12.8V,6.6Ah Pack Capacity (Ah) 6.6 Pack Voltage (V) 12.8 Cell Array 4S6P Number of Cells 24 Cell Model IFR18650-11Q Cell Type Cylindrical
Pack Model 12.8V,11.0Ah Pack Capacity (Ah) 11.0 Pack Voltage (V) 12.8 Cell Array 4S10P Number of Cells 40 Cell Model IFR18650-11Q Cell Type Cylindrical

* The specifications above are for Samsung SDI's representative packs.
Samsung SDI can also provide packs with a custom specification desired by the customer.
