Product features

It's the perfect pack solution for a Power Tool

•
  Extended usage time

  Samsung SDI provides a 3.0 Ah product, which is the world’s highest capacity among the Li-ion battery for power tools. We continue to research and develop a new technology for batteries so as to hold our technology leadership. With increased capacity, power tools can be used for a longer period of time with the same number of cells as the existing products.

•
  Enable light weight

  By using cells with the world’s highest capacity and power, Samsung SDI can make battery packs of the same capacity with fewer cells, which allows for the production of lighter power tools.

•
  Powerful product line-up

  Samsung SDI has an extensive line-up of cells with various power and capacity that can be used in any power tool. We can provide a cell that best suits a customer’s needs.

•
  World’s No. 1 Li-ion battery for power tools

  Samsung SDI’s Li-ion battery cells for power tools are the most frequently purchased battery packs by major power tool companies worldwide. Their outstanding quality and safety contribute to the improved quality and performance of the power tools produced by our customers.

Product specifications

• Cylindrical Cell Show specs

  Cell Model, Type, Thick/Diameter(mm), Height(mm), Capacity(mAh), Nominal Voltage(V), Max Continuous Discharge Current(A)

  Cell Model	Type	Thick/Diameter (mm)	Height (mm)	Capacity (mAh)	Nominal Voltage(V)	Max Continuous Discharge Current(A)
  Cell Model INR18650-13L	Type Cylindrical	Thick/Diameter (mm) 18	Height (mm) 65	Capacity (mAh) 1,300	Nominal Voltage(V) 3.60	Max Continuous Discharge Current(A) 18
  Cell Model INR18650-13M	Type Cylindrical	Thick/Diameter (mm) 18	Height (mm) 65	Capacity (mAh) 1,300	Nominal Voltage(V) 3.60	Max Continuous Discharge Current(A) 23
  Cell Model INR18650-15L	Type Cylindrical	Thick/Diameter (mm) 18	Height (mm) 65	Capacity (mAh) 1,500	Nominal Voltage(V) 3.60	Max Continuous Discharge Current(A) 18
  Cell Model INR18650-15M	Type Cylindrical	Thick/Diameter (mm) 18	Height (mm) 65	Capacity (mAh) 1,500	Nominal Voltage(V) 3.60	Max Continuous Discharge Current(A) 23
  Cell Model INR18650-20Q	Type Cylindrical	Thick/Diameter (mm) 18	Height (mm) 65	Capacity (mAh) 2,000	Nominal Voltage(V) 3.60	Max Continuous Discharge Current(A) 15
  Cell Model INR18650-20R	Type Cylindrical	Thick/Diameter (mm) 18	Height (mm) 65	Capacity (mAh) 2,000	Nominal Voltage(V) 3.60	Max Continuous Discharge Current(A) 22
  Cell Model INR18650-25R	Type Cylindrical	Thick/Diameter (mm) 18	Height (mm) 65	Capacity (mAh) 2,500	Nominal Voltage(V) 3.60	Max Continuous Discharge Current(A) 20

  * Cells with specification different from the above products can be provided upon customer’s request.
