Tablet

Samsung SDI’s ultra-thin and ultra-light Li-ion battery enables tablets to be much slimmer and lighter

Samsung SDI has the leading technology for highest energy density cells, various polymer cell/pack line-up, and pack design technology, which allows it to produce the slimmest and lightest tablets.

Samsung SDI Li-ion Battery - Tablet

Product features

It’s the perfect cell solution for a Tablet

  • Samsung SDI Tablet Battery Cell - Longer battery usage time
    Longer battery life

    Samsung SDI's Li-ion battery has been developed with the company’s unique, differentiated technology such as high-density active materials and a high-voltage design. Our Li-ion battery cells have the world’s highest energy density which allows a single charge of tablet PC will last longer.

  • Samsung SDI Tablet Battery Cell - Smaller volume and weight
    Smaller volume and weight

    Samsung SDI's polymer battery line-up sets a standard for the Li-ion battery industry with its slim and compact-sized cells and allows tablets to be slimmer and lighter than ever.

  • Samsung SDI Tablet Battery Cell - Proven quality and safety system
    Samsung SDI's proven quality and safety system

    Samsung SDI is proud to be the first Li-ion battery producer to receive the ISO/IEC 17025 certification, which is the international standard for quality assurance, in 2011. Building on our reputation for quality and safety, Samsung SDI continues to serve as a dependable developer and producer of quality batteries.

Product specifications

  • Samsung SDI Polymer Battery Cell for Tablet Polymer Cell Show specs
    Cell Model, Type, Thick/Diameter(mm), Width(mm), Height(mm), Capacity(mAh), Nominal Voltage(V), Energy(Wh)
    Cell Model Type Thick/Diameter
    (mm)    		 Width
    (mm)    		 Height
    (mm)    		 Capacity
    (mAh)    		 Nominal
    Voltage(V)    		 Energy
    (Wh)
    Cell Model PGF3183A2 Type Polymer Thick/Diameter (mm) 3.1 Width (mm) 83 Height (mm) 102 Capacity (mAh) 3,030 Nominal Voltage(V) 3.70 Energy (Wh) 11.21
    Cell Model PGF3183A3 Type Polymer Thick/Diameter (mm) 3.1 Width (mm) 83 Height (mm) 103 Capacity (mAh) 3,260 Nominal Voltage(V) 3.70 Energy (Wh) 12.06
    Cell Model PGF3383F0 Type Polymer Thick/Diameter (mm) 3.3 Width (mm) 83 Height (mm) 150 Capacity (mAh) 4,890 Nominal Voltage(V) 3.70 Energy (Wh) 18.09
    Cell Model PGF3480A9 Type Polymer Thick/Diameter (mm) 3.4 Width (mm) 80 Height (mm) 109 Capacity (mAh) 3,740 Nominal Voltage(V) 3.70 Energy (Wh) 13.84
    Cell Model PGF3676B1 Type Polymer Thick/Diameter (mm) 3.6 Width (mm) 76 Height (mm) 111 Capacity (mAh) 3,400 Nominal Voltage(V) 3.70 Energy (Wh) 12.58
    Cell Model PGF368487 Type Polymer Thick/Diameter (mm) 3.6 Width (mm) 84 Height (mm) 87 Capacity (mAh) 3,000 Nominal Voltage(V) 3.70 Energy (Wh) 11.10
    Cell Model PGF397281 Type Polymer Thick/Diameter (mm) 3.9 Width (mm) 72 Height (mm) 81 Capacity (mAh) 2,500 Nominal Voltage(V) 3.70 Energy (Wh) 9.25
    Cell Model PGF405673 Type Polymer Thick/Diameter (mm) 4.0 Width (mm) 56 Height (mm) 73 Capacity (mAh) 2,000 Nominal Voltage(V) 3.70 Energy (Wh) 7.40
    Cell Model PGF4068D0 Type Polymer Thick/Diameter (mm) 4.0 Width (mm) 68 Height (mm) 130 Capacity (mAh) 4,170 Nominal Voltage(V) 3.70 Energy (Wh) 15.43
    Cell Model PGF4175A3 Type Polymer Thick/Diameter (mm) 4.1 Width (mm) 75 Height (mm) 103 Capacity (mAh) 3,430 Nominal Voltage(V) 3.70 Energy (Wh) 12.69
    Cell Model PGF486789 Type Polymer Thick/Diameter (mm) 4.8 Width (mm) 67 Height (mm) 89 Capacity (mAh) 3,550 Nominal Voltage(V) 3.70 Energy (Wh) 13.14
    Cell Model PGF556371 Type Polymer Thick/Diameter (mm) 5.5 Width (mm) 63 Height (mm) 71 Capacity (mAh) 3,030 Nominal Voltage(V) 3.75 Energy (Wh) 11.36
    Cell Model ICP446584 Type 3 Thick/Diameter (mm) 4.4 Width (mm) 65 Height (mm) 84 Capacity (mAh) 3,200 Nominal Voltage(V) 3.80 Energy (Wh) 12.16

    * Cells with specification different from the above products can be provided upon customer’s request.

Cell Model, Type, Thick/Diameter(mm), Width(mm), Height(mm), Capacity(mAh), Nominal Voltage(V), Energy(Wh)
Cell Model Type Thick/Diameter
(mm)		 Width
(mm)		 Height
(mm)		 Capacity
(mAh)		 Nominal
Voltage(V)		 Energy
(Wh)
Cell Model PGF3183A2 Type Polymer Thick/Diameter (mm) 3.1 Width (mm) 83 Height (mm) 102 Capacity (mAh) 3,030 Nominal Voltage(V) 3.70 Energy (Wh) 11.21
Cell Model PGF3183A3 Type Polymer Thick/Diameter (mm) 3.1 Width (mm) 83 Height (mm) 103 Capacity (mAh) 3,260 Nominal Voltage(V) 3.70 Energy (Wh) 12.06
Cell Model PGF3383F0 Type Polymer Thick/Diameter (mm) 3.3 Width (mm) 83 Height (mm) 150 Capacity (mAh) 4,890 Nominal Voltage(V) 3.70 Energy (Wh) 18.09
Cell Model PGF3480A9 Type Polymer Thick/Diameter (mm) 3.4 Width (mm) 80 Height (mm) 109 Capacity (mAh) 3,740 Nominal Voltage(V) 3.70 Energy (Wh) 13.84
Cell Model PGF3676B1 Type Polymer Thick/Diameter (mm) 3.6 Width (mm) 76 Height (mm) 111 Capacity (mAh) 3,400 Nominal Voltage(V) 3.70 Energy (Wh) 12.58
Cell Model PGF368487 Type Polymer Thick/Diameter (mm) 3.6 Width (mm) 84 Height (mm) 87 Capacity (mAh) 3,000 Nominal Voltage(V) 3.70 Energy (Wh) 11.10
Cell Model PGF397281 Type Polymer Thick/Diameter (mm) 3.9 Width (mm) 72 Height (mm) 81 Capacity (mAh) 2,500 Nominal Voltage(V) 3.70 Energy (Wh) 9.25
Cell Model PGF405673 Type Polymer Thick/Diameter (mm) 4.0 Width (mm) 56 Height (mm) 73 Capacity (mAh) 2,000 Nominal Voltage(V) 3.70 Energy (Wh) 7.40
Cell Model PGF4068D0 Type Polymer Thick/Diameter (mm) 4.0 Width (mm) 68 Height (mm) 130 Capacity (mAh) 4,170 Nominal Voltage(V) 3.70 Energy (Wh) 15.43
Cell Model PGF4175A3 Type Polymer Thick/Diameter (mm) 4.1 Width (mm) 75 Height (mm) 103 Capacity (mAh) 3,430 Nominal Voltage(V) 3.70 Energy (Wh) 12.69
Cell Model PGF486789 Type Polymer Thick/Diameter (mm) 4.8 Width (mm) 67 Height (mm) 89 Capacity (mAh) 3,550 Nominal Voltage(V) 3.70 Energy (Wh) 13.14
Cell Model PGF556371 Type Polymer Thick/Diameter (mm) 5.5 Width (mm) 63 Height (mm) 71 Capacity (mAh) 3,030 Nominal Voltage(V) 3.75 Energy (Wh) 11.36
Cell Model ICP446584 Type 3 Thick/Diameter (mm) 4.4 Width (mm) 65 Height (mm) 84 Capacity (mAh) 3,200 Nominal Voltage(V) 3.80 Energy (Wh) 12.16

* Cells with specification different from the above products can be provided upon customer’s request.

Click on the button to move to the page.
Inquiry

Product features

It’s the perfect pack solution for a Tablet

  • Samsung SDI Tablet Battery Pack - A wide selection of battery packs for tablet
    A wide selection of battery packs for tablet

    Samsung SDI has an extensive polymer battery pack line-up for the tablet. We can supply a battery pack most suitable for the customer’s demand, thereby enhancing design flexibility.

  • Samsung SDI Tablet Battery Pack - Smaller volume and weight
    Smaller volume and weight

    Samsung SDI provides the ever lighter and slimmer design through constant innovation of lighter and optimized materials for battery packs.

Product specifications

  • Samsung SDI Battery Pack for Tablet Pack Show specs
    Pack Model, Pack Capacity(Ah), Pack Voltage(V), Energy(Wh), Cell Array, Number of Cells, Cell Model, Cell Type
    Pack Model Pack Capacity
    (Ah)    		 Pack Voltage
    (V)    		 Energy
    (Wh)    		 Cell Array Number of Cells Cell Model Cell Type
    Pack Model 3.7V,4.0Ah Pack Capacity (Ah) 4.0 Pack Voltage (V) 3.7 Energy (Wh) 14.8 Cell Array 1S1P Number of Cells 1 Cell Model PGF4960C3 Cell Type Polymer
    Pack Model 3.7V,7.0Ah Pack Capacity (Ah) 7.0 Pack Voltage (V) 3.7 Energy (Wh) 25.9 Cell Array 1S2P Number of Cells 2 Cell Model PGF3676B1 Cell Type Polymer

    * The specifications above are for Samsung SDI's representative packs.
    Samsung SDI can also provide packs with a custom specification desired by the customer.

Pack Model, Pack Capacity(Ah), Pack Voltage(V), Energy(Wh), Cell Array, Number of Cells, Cell Model, Cell Type
Pack Model Pack Capacity
(Ah)		 Pack Voltage
(V)		 Energy
(Wh)		 Cell Array Number of Cells Cell Model Cell Type
Pack Model 3.7V,4.0Ah Pack Capacity (Ah) 4.0 Pack Voltage (V) 3.7 Energy (Wh) 14.8 Cell Array 1S1P Number of Cells 1 Cell Model PGF4960C3 Cell Type Polymer
Pack Model 3.7V,7.0Ah Pack Capacity (Ah) 7.0 Pack Voltage (V) 3.7 Energy (Wh) 25.9 Cell Array 1S2P Number of Cells 2 Cell Model PGF3676B1 Cell Type Polymer

* The specifications above are for Samsung SDI's representative packs.
Samsung SDI can also provide packs with a custom specification desired by the customer.

Manufacturing process

Tablet

Watch how the Samsung SDI's Li-ion Battery cell is developed into a battery pack
