Product features

It's the perfect solution for a Power Bank

•
  Diverse line-up of power bank cells and packs

  Samsung SDI provides battery cells and packs (power bank) with various specifications to the customers. Cylindrical battery cells with various capacities, including the cell with the world’s highest energy density, and prismatic battery cells with various specifications allow the customer to produce a power bank suited to the customer’s needs and preferences.

•
  World’s longest battery life cycle

  Samsung SDI battery cells and packs for power bank has achieved world’s longest battery life cycle. They minimize the capacity loss that may occur during long-term usage and thereby maximizes the user’s convenience.

•
  Proven safety and quality

  Samsung SDI’s manufacturing process has been developed with the safety of the product as its first priority, and it enables the highest level of safety and quality of the product.

Product specifications

• Cylindrical Cell Show specs

  Cell Model, Type, Thick/Diameter(mm), Height(mm), Capacity(mAh), Nominal Voltage(V), Energy(Wh)

  Cell Model	Type	Thick/Diameter (mm)	Height (mm)	Capacity (mAh)	Nominal Voltage(V)	Energy (Wh)
  Cell Model ICR18650-22F	Type Cylindrical	Thick/Diameter(mm) 18	Height(mm) 65	Capacity(mAh) 2,200	Nominal Voltage(V) 3.60	Energy(Wh) 7.92
  Cell Model ICR18650-26H	Type Cylindrical	Thick/Diameter(mm) 18	Height(mm) 65	Capacity(mAh) 2,600	Nominal Voltage(V) 3.63	Energy(Wh) 9.44
  Cell Model ICR18650-30A	Type Cylindrical	Thick/Diameter(mm) 18	Height(mm) 65	Capacity(mAh) 2,950	Nominal Voltage(V) 3.78	Energy(Wh) 11.15
  Cell Model INR18650-20R	Type Cylindrical	Thick/Diameter(mm) 18	Height(mm) 65	Capacity(mAh) 2,000	Nominal Voltage(V) 3.60	Energy(Wh) 7.20

  * Cells with specification different from the above products can be provided upon customer’s request.

• Prismatic Cell Show specs

  Cell Model, Type, Thick/Diameter(mm), Width(mm), Height(mm), Capacity(mAh), Nominal Voltage(V), Energy(Wh)

  Cell Model	Type	Thick/Diameter (mm)	Width (mm)	Height (mm)	Capacity (mAh)	Nominal Voltage(V)	Energy (Wh)
  Cell Model ICP103450	Type Prismatic	Thick/Diameter(mm) 10	Width(mm) 34	Height(mm) 50	Capacity(mAh) 2,200	Nominal Voltage(V) 3.80	Energy(Wh) 8.36
  Cell Model ICP464665	Type Prismatic	Thick/Diameter(mm) 4.6	Width(mm) 46	Height(mm) 65	Capacity(mAh) 1,670	Nominal Voltage(V) 3.70	Energy(Wh) 6.18
  Cell Model ICP515161	Type Prismatic	Thick/Diameter(mm) 5.1	Width(mm) 51	Height(mm) 61	Capacity(mAh) 2,100	Nominal Voltage(V) 3.80	Energy(Wh) 7.98
  Cell Model ICP596080	Type Prismatic	Thick/Diameter(mm) 5.9	Width(mm) 60	Height(mm) 80	Capacity(mAh) 3,780	Nominal Voltage(V) 3.80	Energy(Wh) 14.36
  Cell Model ICP666480	Type Prismatic	Thick/Diameter(mm) 6.6	Width(mm) 64	Height(mm) 80	Capacity(mAh) 4,452	Nominal Voltage(V) 3.80	Energy(Wh) 16.92
  Cell Model ICP903864	Type Prismatic	Thick/Diameter(mm) 9	Width(mm) 38	Height(mm) 64	Capacity(mAh) 3,030	Nominal Voltage(V) 3.80	Energy(Wh) 11.51

  * Cells with specification different from the above products can be provided upon customer’s request.

• Pack Show specs

  Pack Model, Pack Capacity(Ah), Pack Voltage(V), Energy(Wh), Cell Array, Number of Cells, Cell Model, Cell Type

  Pack Model	Pack Capacity (Ah)	Pack Voltage (V)	Energy (Wh)	Cell Array	Number of Cells	Cell Model	Cell Type
  Pack Model 3.60V,2.0Ah	Pack Capacity(Ah) 2.0	Pack Voltage(V) 3.60	Energy(Wh) 7.20	Cell Array 1S1P	Number of Cells 1	Cell Model INR18650-20R	Cell Type Cylindrical
  Pack Model 3.60V,4.0Ah	Pack Capacity(Ah) 4.0	Pack Voltage(V) 3.60	Energy(Wh) 14.40	Cell Array 1S2P	Number of Cells 2	Cell Model INR18650-20R	Cell Type Cylindrical
  Pack Model 3.78V,9.0Ah	Pack Capacity(Ah) 9.0	Pack Voltage(V) 3.78	Energy(Wh) 34.02	Cell Array 1S3P	Number of Cells 3	Cell Model ICR18650-30A	Cell Type Cylindrical
  Pack Model 3.8V,3.0Ah	Pack Capacity(Ah) 3.0	Pack Voltage(V) 3.80	Energy(Wh) 11.40	Cell Array 1S1P	Number of Cells 1	Cell Model ICP575673A	Cell Type Prismatic

  * The specifications above are for Samsung SDI's representative packs.
  Samsung SDI can also provide packs with a custom specification desired by the customer.
