E-Bike

Samsung SDI, the Total Battery Solution Provider

Samsung SDI’s high-capacity and high-quality cell technology enhances the mobility of E-Bike with its differentiated design and performance.

Samsung SDI Li-ion Battery – E Bike

Product features

It’s the perfect cell solution for an E-bike

  • Samsung SDI Cylindrical Battery Cell for E-Bike - Extend driving distance
    Extend driving distance

    Samsung SDI provides high capacity 3.5Ah (35E) cells for E-bikes. High capacity cells such as 3.5 Ah improve the driving distance of the E-bike and provide convenience to the customers.

  • Samsung SDI Cylindrical Battery Cell for E-Bike - Enhance design flexibility
    Enhance design flexibility

    Samsung SDI’s high capacity 3.5Ah (35E) cells enable the design of battery packs with less number of cells but with the same capacity. Using the lighter and slimmer battery packs, the customers will be able to develop E-bikes with varied and differentiated designs.

  • Samsung SDI Cylindrical Battery Cell for E-Bike - Improve safety and quality
    Improve safety and quality

    Since the cells in E-bike battery packs should be connected in serial-parallel, cell balance is one of the most important factors determining the product quality.
    Samsung SDI’s superb cell balance technology contributes to the uniform quality of the packs and driving units, and ultimately to the quality of the E-bike. Our batteries help to provide E-bikes with reliable quality to the consumers. As a testimony to their outstanding quality and safety, Samsung SDI’s Li-ion battery cells are preferred by high-end E-bike makers and driving unit companies that lead the E-bike market.

Product specifications

  • Samsung SDI Cylindrical Battery Cell for E-Bike Cylindrical Cell Show specs
    Cell Model, Type, Thick/Diameter(mm), Height(mm), Capacity(mAh), Nominal Voltage(V), Max Continuous Discharge Current
    Cell Model Type Thick/Diameter
    (mm)    		 Height (mm) Capacity
    (mAh)    		 Nominal
    Voltage(V)    		 Max Continuous
    Discharge Curr
    ent
    Cell Model ICR18650-22P Type Cylindrical Thick/Diameter (mm) 18 Height (mm) 65 Capacity (mAh) 2,150 Nominal Voltage(V) 3.62 Energy (Wh) 3C
    Cell Model ICR18650-29E Type Cylindrical Thick/Diameter (mm) 18 Height (mm) 65 Capacity (mAh) 2,850 Nominal Voltage(V) 3.65 Energy (Wh) 2C

    * Cells with specification different from the above products can be provided upon customer’s request.

Cell Model, Type, Thick/Diameter(mm), Height(mm), Capacity(mAh), Nominal Voltage(V), Max Continuous Discharge Current
Cell Model Type Thick/Diameter
(mm)		 Height (mm) Capacity
(mAh)		 Nominal
Voltage(V)		 Max Continuous
Discharge Curr
ent
Cell Model ICR18650-22P Type Cylindrical Thick/Diameter (mm) 18 Height (mm) 65 Capacity (mAh) 2,150 Nominal Voltage(V) 3.62 Energy (Wh) 3C
Cell Model ICR18650-29E Type Cylindrical Thick/Diameter (mm) 18 Height (mm) 65 Capacity (mAh) 2,850 Nominal Voltage(V) 3.65 Energy (Wh) 2C

* Cells with specification different from the above products can be provided upon customer’s request.

Click on the button to move to the page.
Inquiry

Product features

It's the perfect pack solution for an E-bike

  • Samsung SDI Battery Pack for E-Bike - Improve safety with the Samsung SDI’s safety protection function
    Improve safety with the Samsung SDI’s safety protection function

    Since an E-bike’s battery pack typically has about 20~65 battery cells, it is very important to ensure the safety of the pack. Safety protection function of Samsung SDI’s pack improves the safety of the E-bike by automatically disconnecting electric power when the battery is in danger.

  • Samsung SDI Battery Pack for E-Bike - Extend driving distance with regenerative charging
    Extend driving distance with regenerative charging

    The regenerative charging converts otherwise wasted energy while driving on a downhill road into electricity and may further extend the driving distance of the E-bike.

  • Samsung SDI Battery Pack for E-Bike - Reduce recharging time
    Reduce recharging time

    Samsung SDI is developing a quick charging technology that could reduce the recharging time from 150 to 30 minutes to fully recharge the battery, making the E-bike more convenient for users.

  • Samsung SDI Battery Pack for E-Bike - Receive full support by the exclusive E-bike pack development team
    Receive full support by the exclusive E-bike pack development team

    Samsung SDI has a team committed to developing packs for the E-bike, and responds to customer demands in a professional and timely manner.

Product specifications

  • Samsung SDI Battery Pack for E-Bike Pack Show specs
    Pack Model, Pack Capacity(Ah), Pack Voltage(V), Cell Array, Number of Cells, Cell Model, Cell Type
    Pack Model Pack Capacity
    (Ah)    		 Pack Voltage
    (V)    		 Cell Array Number of Cells Cell Model Cell Type
    Pack Model 24.0V,10.8Ah Pack Capacity (Ah) 10.8 Pack Voltage (V) 24.0 Cell Array 7S4P Number of Cells 28 Cell Model ICR18650-26H Cell Type Cylindrical
    Pack Model 24.0V,8.8Ah Pack Capacity (Ah) 8.8 Pack Voltage (V) 24.0 Cell Array 7S4P Number of Cells 28 Cell Model ICR18650-22P Cell Type Cylindrical
    Pack Model 25.0V,6.4Ah Pack Capacity (Ah) 6.4 Pack Voltage (V) 25.0 Cell Array 7S3P Number of Cells 21 Cell Model ICR18650-22P Cell Type Cylindrical
    Pack Model 36.0V,10.8Ah Pack Capacity (Ah) 10.8 Pack Voltage (V) 36.0 Cell Array 10S4P Number of Cells 40 Cell Model ICR18650-26H Cell Type Cylindrical
    Pack Model 36.0V,6.4Ah Pack Capacity (Ah) 6.4 Pack Voltage (V) 36.0 Cell Array 10S3P Number of Cells 30 Cell Model ICR18650-22P Cell Type Cylindrical
    Pack Model 36.0V,8.5Ah Pack Capacity (Ah) 8.2 Pack Voltage (V) 36.0 Cell Array 10S3P Number of Cells 30 Cell Model ICR18650-29E Cell Type Cylindrical
    Pack Model 36.0V,8.6Ah Pack Capacity (Ah) 10.8 Pack Voltage (V) 36.0 Cell Array 10S4P Number of Cells 40 Cell Model ICR18650-22P Cell Type Cylindrical

    * The specifications above are SAMSUNG SDI's representative pack informations.
    Aside from those products, we can provide customized packs according to the customer's needs and specifications.

Pack Model, Pack Capacity(Ah), Pack Voltage(V), Cell Array, Number of Cells, Cell Model, Cell Type
Pack Model Pack Capacity
(Ah)		 Pack Voltage
(V)		 Cell Array Number of Cells Cell Model Cell Type
Pack Model 24.0V,10.8Ah Pack Capacity (Ah) 10.8 Pack Voltage (V) 24.0 Cell Array 7S4P Number of Cells 28 Cell Model ICR18650-26H Cell Type Cylindrical
Pack Model 24.0V,8.8Ah Pack Capacity (Ah) 8.8 Pack Voltage (V) 24.0 Cell Array 7S4P Number of Cells 28 Cell Model ICR18650-22P Cell Type Cylindrical
Pack Model 25.0V,6.4Ah Pack Capacity (Ah) 6.4 Pack Voltage (V) 25.0 Cell Array 7S3P Number of Cells 21 Cell Model ICR18650-22P Cell Type Cylindrical
Pack Model 36.0V,10.8Ah Pack Capacity (Ah) 10.8 Pack Voltage (V) 36.0 Cell Array 10S4P Number of Cells 40 Cell Model ICR18650-26H Cell Type Cylindrical
Pack Model 36.0V,6.4Ah Pack Capacity (Ah) 6.4 Pack Voltage (V) 36.0 Cell Array 10S3P Number of Cells 30 Cell Model ICR18650-22P Cell Type Cylindrical
Pack Model 36.0V,8.5Ah Pack Capacity (Ah) 8.2 Pack Voltage (V) 36.0 Cell Array 10S3P Number of Cells 30 Cell Model ICR18650-29E Cell Type Cylindrical
Pack Model 36.0V,8.6Ah Pack Capacity (Ah) 10.8 Pack Voltage (V) 36.0 Cell Array 10S4P Number of Cells 40 Cell Model ICR18650-22P Cell Type Cylindrical

* The specifications above are SAMSUNG SDI's representative pack informations.
Aside from those products, we can provide customized packs according to the customer's needs and specifications.

Manufacturing process

E-Bike

Watch how the Samsung SDI's Li-ion Battery cell is developed into a battery pack
